Low carbon steel plate refers to those the carbon content among 0.04–0.3% which is a comparative low standard. Low carbon steel plate has lower strength relative to higher carbon content steel plate. But low carbon steel plates have excellent machinability and weldability. Mild steel plate is a typically low carbon steel plate. Besides, ASTM A36, A572 Grades 42 & 50 and A830-1020 are the common low carbon steel grades, too.
Due to its high strength-to-weight ratio, formability and excellent welding properties, low carbon steel plate becomes one of the most widely used carbon structural steels. It widely used in constructing various structures and components, such as bridge, building, automobile, ship and so on. It can even used in other application, such as bolts, nails, screws, and other fasteners manufacturing. Low carbon steel has a various of dimension, thickness, width, length, shape, surface finish, which ensure it become more versatile.
| Grade | Carbon Max | Manganese | Phosphorus Max | Sulfur Max | Silicon |
| A36 up to 3/4” thick | 0.25% | N/A | 0.03% | 0.03% | 0.40% Max |
| A36 >3/4 – 1 ½” thick | 0.25% | 0.80-1.20% | 0.03% | 0.03% | 0.40% Max |
| A36 > 1 ½ - 2 ½” thick | 0.26% | 0.80-1.20% | 0.03% | 0.03% | 0.15-0.40% |
| A36 >2 ½ - 4” thick | 0.27% | 0.85-1.20% | 0.03% | 0.03% | 0.15-0.40% |
| A36 >4” thick | 0.29% | 0.85-1.20% | 0.03% | 0.03% | 0.15-0.40% |
| A572 Grade 42 | 0.21% | 1.35% | 0.03% | 0.03% | 0.15-0.40% |
| A572 Grade 50 | 0.23% | 1.35% | 0.03% | 0.03% | 0.15-0.40% |
| A830 Grade 1020 | 0.18-0.23% | 0.30-0.60% | 0.03% | 0.03% | N/A |
| Mechanical Properties of Common Low Carbon Plate Grades | ||
| Grade | Yield Point | Tensile |
| A36 | 36 ksi | 58-80 ksi |
| A572 Grade 42 | 42 ksi | 60 ksi |
| A572 Grade 50 | 50 ksi | 65 ksi |
Steel plate and plate cut from coil can be used in a variety of industries and applications, as it is a very versatile and commonly used form of steel.
Carbon steel has a large number of applications in the field of construction, mainly used in building structures and reinforced concrete formwork.
Carbon steel also has important applications in shipbuilding. It is mainly used to build the main structure of the ship, such as the hull, deck, bow, stern and other parts.
Widely used in oil and gas extraction, transportation and processing. It is used in the manufacture of oil well pipes, pipelines, drilling pipes and other petroleum equipment.
Carbon steel is widely used to manufacture a variety of mechanical equipment and parts, such as automobiles, ships, airplanes and construction machinery etc.
