Inconel alloy steel wire, a high-performance nickel-based alloy material, has excellent resistance to high temperatures, corrosion and mechanical strength.
High Temperature Resistance: Inconel steel wire is able to withstand extreme high temperature environments and can typically be used at temperatures up to hundreds to thousands of degrees Celsius, depending on the grade of the alloy. This makes it an ideal material for high temperature applications such as gas turbines, jet engines and other components.
Corrosion resistance: Inconel steel wire has excellent resistance to a wide range of corrosive media, including acids, alkalis and salts. This corrosion resistance makes it widely used in harsh environments such as chemical processing and marine engineering.
Good mechanical properties: Inconel steel wire can still maintain good mechanical strength, such as tensile strength, yield strength and hardness at higher temperatures. This allows it to maintain stable performance even when exposed to high temperatures and mechanical loads for long periods of time.
| Inconel | Element, proportion by mass (%) | ||||||||||||||
| Ni | Cr | Fe | Mo | Nb & Ta | Co | Mn | Cu | Al | Ti | Si | C | S | P | B | |
| 600 | ≥72.0[a] | 14.0–17.0 | 6.0–10.0 | — | ≤1.0 | ≤0.5 | ≤0.5 | ≤0.15 | ≤0.015 | ||||||
| 617 | 44.2–61.0 | 20.0–24.0 | ≤3.0 | 8.0–10.0 | 10.0–15.0 | ≤0.5 | ≤0.5 | 0.8–1.5 | ≤0.6 | ≤0.5 | 0.05–0.15 | ≤0.015 | ≤0.015 | ≤0.006 | |
| 625 | ≥58.0 | 20.0–23.0 | ≤5.0 | 8.0–10.0 | 3.15–4.15 | ≤1.0 | ≤0.5 | ≤0.4 | ≤0.4 | ≤0.5 | ≤0.1 | ≤0.015 | ≤0.015 | ||
| 690 | ≥58 | 27–31 | 7–11 | ≤0.50 | ≤0.50 | ≤0.50 | ≤0.05 | ≤0.015 | |||||||
| Nuclear grade 690 | ≥58 | 28–31 | 7–11 | ≤0.10 | ≤0.50 | ≤0.50 | ≤0.50 | ≤0.04 | ≤0.015 | ||||||
| 718 | 50.0–55.0 | 17.0–21.0 | Balance | 2.8–3.3 | 4.75–5.5 | ≤1.0 | ≤0.35 | ≤0.3 | 0.2–0.8 | 0.65–1.15 | ≤0.35 | ≤0.08 | ≤0.015 | ≤0.015 | ≤0.006 |
| X-750 | ≥70.0 | 14.0–17.0 | 5.0–9.0 | 0.7–1.2 | ≤1.0 | ≤1.0 | ≤0.5 | 0.4–1.0 | 2.25–2.75 | ≤0.5 | ≤0.08 | ≤0.01 | |||
Inconel coil can be used in a variety of industries and applications, as it is a very versatile and commonly used form of steel.
Inconel alloy tubes are also widely used in the field of nuclear energy, such as control rods and fuel elements in nuclear reactors, which need to withstand extreme conditions of high temperature, radiation and corrosion.
Inconel alloy tubes are used in the manufacture of engine parts for airplanes and rockets, high-temperature structural parts, etc., which are able to withstand extreme environments of high temperature and high pressure.
In the petrochemical industry, Inconel alloy tubes are used in the manufacture of reactors, heat exchangers, pipelines and other corrosion-resistant equipment, capable of withstanding corrosive media and high temperature and pressure environments.
cIn the marine environment, Inconel alloy tubes are used to manufacture desalination equipment, marine platforms and other corrosion-resistant structures, able to withstand seawater corrosion and wave impact and other harsh environments.
