Hastelloy tubing, or Hastelloy tubing, is the collective name for commercial grades of nickel-based corrosion-resistant alloy tubing produced by Hastelloy International, Inc. in the United States.
1.Corrosion resistance: Hastelloy tubes have excellent corrosion resistance and are able to resist a wide range of corrosive media, such as acids, alkalis and salts.
2.High Temperature Resistance: Some Hastelloy tube models (such as Hastelloy X) have excellent high temperature performance, able to maintain stable performance in high temperature environments.
3.Mechanical properties: Hastelloy tubes have good mechanical properties, such as strength, toughness and hardness, etc., to meet the requirements of use in different fields.
| Generic term | UNS No | DIN/EN | Composition |
| Hastelloy C-276 | N10276 | 2.4819 | 57Ni-16Mo-16Cr-5Fe-4W-2.5Co-1Mn-0.35V-0.08Si-0.01C |
| Hastelloy C-4 | N06455 | 2.461 | 65Ni-16Cr-16Mo-0.7Ti-3Fe-2Co-1Mn-0.08Si-0.01C |
| Hastelloy C-22 | N06022 | 2.4602 | 56Ni-22Cr-13Mo-3Fe-2.5Co-0.5Mn-0.35V-0.08Si-0.01C |
| Hastelloy C-2000 | N06200 | 2.4675 | 59Ni-23Cr-16Mo-1.6Cu-0.08Si-0.01C |
| Hastelloy X | N06002 | 2.4665 | 47Ni-22Cr-18Fe-9Mo-1.5Co-0.6W-0.1C-1mn-1Si-0.008B |
| Hastelloy B-2 | N10665 | 2.4617 | 69Ni-28Mo-0.5Cr-1.8Fe-3W-1.0Co-1.0Mn-0.01C |
| Hastelloy B-3 | N10675 | 2.466 | 65Ni-28.5Mo-1.5Cr-1.5Fe-3W-3Co-3Mn-0.01C |
| Hastelloy G-30 | N06030 | 43Ni-30Cr-15Fe-5.5Mo-2.5W-5Co-2Cu-1.5Mn-0.03C | |
| Hastelloy G-35 | N06035 | 58Ni-33Cr-8Mo-2Fe-0.6Si-0.3Cu-0.03C |
Hastelloy tubing is available in a variety of grades, including but not limited to the following:
Hastelloy C-276: A tungsten-containing nickel-chromium-molybdenum alloy tube containing very low levels of silicon and carbon, it is often considered a universal corrosion-resistant alloy. It has excellent corrosion resistance to most corrosive media in both oxidizing and reducing atmospheres and has outstanding resistance to pitting, crevice corrosion and stress cracking corrosion.
Hastelloy C-22: A versatile nickel-chromium-molybdenum-tungsten alloy tube with improved overall corrosion resistance and excellent resistance to homogeneous corrosion, especially in oxidizing media.
Hastelloy C-2000: A nickel-based, high-temperature alloy tube composed of nickel, molybdenum, and chromium designed to resist a wider range of corrosive compounds, including sulfuric and hydrofluoric acids, and is the most versatile corrosion-resistant alloy available.
Hastelloy C-4: An austenitic, low-carbon nickel-molybdenum-chromium alloy tube that maintains excellent mechanical properties at elevated temperatures and is extremely corrosion resistant. It is suitable for aerospace, chemical and marine engineering.
Hastelloy B-2: a nickel-based high-temperature alloy tube with excellent corrosion resistance and high-temperature performance, widely used in aviation, aerospace, petroleum, chemical and other fields.
Hastelloy B-3: an upgraded version of B-2 with excellent corrosion resistance to hydrochloric acid at any temperature and concentration, a nickel-based high-temperature alloy tube known for its excellent corrosion resistance and high-temperature stability.
Hastelloy X: A nickel-chromium-iron-molybdenum alloy tube with excellent oxidation resistance, manufacturability, and high-temperature strength, commonly used in gas turbine components in aircraft, power plants, and petrochemical plants.
Hastelloy G-30: A nickel-based alloy tube with a high chromium content that has superior corrosion resistance to commercial phosphoric acid and many mixed environments with highly oxidizing acid media such as nitric/hydrochloric, nitric/hydrofluoric, and sulfuric acids compared to most other nickel- and iron-based alloys.Hastelloy G-35: An upgrade from G-30 with even better corrosion resistance and thermal stability.Questions? Contact us Anytime! Fill out the form below with as much information as possible and we will get back to you quickly!
