Stainless steel angle, also called stainless steel angle iron, stainless steel angle bar or stainless steel angle beam. Stainless steel equal angle, as its name indicate, the lengths of both sides of the 'L' are equal, ensuring the angle symmetry and consistency.
There are a series of stainless steel equal angle bars available, such as 304, 304L, 316, 316L, 430, 904L etc.
Stainless steel angle bar has two types: stainless steel equal angle and stainless steel unequal angle. The stainless steel equal angle has both sides of the L in equal lengths while unequal angle's one side of angle is wider than the other side. Equal angle bars are suited for situations which need uniformity in geometric, such as square or rhombus shapes. While unequal angle bars are versatilely widely used in projects where different angles and leg lengths are needed to meet complicated design and load-bearing requirements, such as stairs, ramps, structural framing and supports.
| 25*25*3 | 60*60*5 | 90*90*7 | 150*150*12 |
| 30*30*3 | 65*65*5 | 90*90*10 | 150*150*15 |
| 40*40*3 | 65*65*6 | 90*90*13 | 150*150*19 |
| 40*40*5 | 65*65*8 | 100*100*7 | 175*175*12 |
| 45*45*4 | 70*70*6 | 100*100*10 | 175*175*15 |
| 45*45*5 | 75*75*6 | 100*100*13 | 200*200*15 |
| 50*50*4 | 75*75*9 | 120*120*8 | 200*200*20 |
| 50*50*5 | 75*75*12 | 130*130*9 | 200*200*25 |
| 50*50*6 | 80*80*6 | 130*130*12 | 250*250*25 |
| 60*60*4 | 90*90*6 | 130*130*15 | 259*259*25 |
| L 20*20*3 | L 50*50*4 | L 70*70*8 | L 110 *110*8 |
| L 25*25*3 | L 50*50*6 | L 75*75 4 | L 110*110*12 |
| L 25*25*4 | L 50*50*7 | L 75*75*5 | L 120*120*8 |
| L 30*30*3 | L 55*55*5 | L 80*80*5 | L 120*120*10 |
| L 30*30*4 | L 60*60*4 | L 80*80*6 | L 130*130*13 |
| L 35*35*4 | L 60*60*8 | L 80*80*8 | L 150*150*15 |
| L 40*40*4 | L 65*65*6 | L 90*90*9 | L 160*160*14 |
| L 40*40*5 | L 65*65*7 | L 90*90*10 | L 180*180*13 |
| L 45*45*4 | L 65*65*8 | L 100*100*6 | L 200*200*16 |
| L 45*45*4.5 | L 70*70*6 | L 100*100*7 | L 250*250*20 |
| L19*19*3.2 | L51*51*4.8 | L102*102*11.1 | L203*203*25.4 |
| L25.4*25.4*4.8 | L64*64*7.9 | L102*102*7.9 | L203*203*22.2 |
| L32*32*4.8 | L76*76*9.5 | L127*127*12.7 | L203*203*15.9 |
| L32*32*3.2 | L89*89*9.5 | L127*127*7.9 | L203*203*14.3 |
| L38*38*4.0 | L89*89*6.4 | L152*152*14.3 |
|
| L44.5*44.5*4.8 | L102*102*12.7 | L152*152*7.9 |
| 20*20*3 | 50*50*3 | 75*75*5 | 125*125*10 |
| 25*25*3 | 56*56*4 | 80*80*5 | 140*140*10 |
| 30*30*3 | 60*60*5 | 90*90*7 | 150*150*8 |
| 40*40*3 | 63*63*4 | 100*100*6 | 160*160*12 |
| 45*45*3 | 70*70*4 | 110*110*7 | 180*180*12 |
