A53 Carbon Steel Plate

ASTM A53 steel is a carbon steel alloy, with the property of high strength, high tensile strength. ASTM A53 is intended for mechanical and pressure applications, specially in low pressure. ASTM A53 is an American standard grade, it is equivalent to Q235, St45. A53-F equals to China's q235 material, A53-A equals to China's 10# material, and A53-B corresponds to China's 20# material.

Whatsapp Send E-mail

Specification:

- Thickness: 0.15mm-400mm, or as customized
- Width: 1250mm-2500mm, or as customized
- Length: 1000mm-12000mm, or as customized
- Grade: A36, A53, A283, A285, A369, Gr.A, Gr.B, Gr.C, GR50, GR55, Q195, Q215, Q235, Q345, Q355, Q265, Q275, S25C, S35C, DC01, DC02, SS400, SS490, SM400, SPHC, SPHD, SPHE, SPHF, SPHT1, SPHT2, SPH3, SPH4, etc
- Standard: AISI, ASTM, DIN, JIS, GB, JIS, SUS, EN，etc
- Certification: ISO SGS BV
- Surface: Black painted, PE coated, Galvanized, Galvalumed, etc.

Introduce:

Due to the high strength, and high tensile strength, ASTM A53 is suitable for welding and for forming operations involving coiling, bending, and flanging, subject to certain qualifications. And it is also used in ordinary uses in steam, water, gas and air lines, and pipelines. ASTM A53 has two grades: grade A and grade B. ASTM A53 Grade B has higher strength and resilience. Therefore ASTM A53 Grade B is more suitable used in industrial, plumbing, and mechanical while Grade A is suitable for general structural and low-pressure.

Chemical Composition

Chemical Composition
ASTM A53	Grade	C	Mn	P	S	Si	Cr	Ni	Cu
ASTM A53 Grade A	10#	0.07-0.14	0.35-0.65	≤0.35	≤0.035	0.17-0.37	≤0.15	≤0.25	≤0.25
ASTM A53 Grade B	20#	0.17-0.24	0.35-0.65	≤0.035	≤0.035	0.17-0.37	≤0.25	≤0.25	≤0.25

Unfold

Application

Steel plate and plate cut from coil can be used in a variety of industries and applications, as it is a very versatile and commonly used form of steel.

Some common industries and applications include:

Construction

Carbon steel has a large number of applications in the field of construction, mainly used in building structures and reinforced concrete formwork.
Shipbuiding

Carbon steel also has important applications in shipbuilding. It is mainly used to build the main structure of the ship, such as the hull, deck, bow, stern and other parts.
Oil and Gas

Widely used in oil and gas extraction, transportation and processing. It is used in the manufacture of oil well pipes, pipelines, drilling pipes and other petroleum equipment.
Mechanical

Carbon steel is widely used to manufacture a variety of mechanical equipment and parts, such as automobiles, ships, airplanes and construction machinery etc.
